Grundfos 98280893 - Model SEG.A20, Submersible Wastewater Pump - SEG.A20.55.2.60H

Grundfos 98280893, Model SEG.A20, SEG Series, Submersible Wastewater Pumps, 5-1/2 HP, 460 Volts, 3 Phase, 2" NPT Vertical Discharge, 159 GPM Max, 107 ft. Max Head

Grundfos SEG Series:

The SEG range of grinder pumps from Grundfos is specifically designed for pumping effluent and untreated sewage.

Application:

• Plumbing: Wastewater
• Residential wastewater
• Stormwater control
• Municipal wastewater transport

Features:

• Cartridge shaft seal system, together with the polyurethane- sealed cable plug system, prevent liquid from penetrating into the motor.
• Compact construction with short shaft outside bearings, ensures less stress on bearings and, consequently, longer lifetime.
• Double mechanical cartridge shaft seal system provides longer operating time and less downtime - easy to replace in the field without use of special tools.
• Feet on the pump housing facilitate suction for freestanding installation.
• Unique clamp system enables quick and easy dismantling of pump and motor unit and enables 180° rotation of motor housing.
• Specially designed lifting handle ensures correct lifting regardless of installation or motor positioning.
• Built-in thermal switches in the motor windings provide protection against overheating, ensuring a long lifetime.
• Leakage detection for protection against water intrusions in case of component failure.
• Patented grinder system ensures extremely high efficiency and reliable operation with quick and easy dismantling for replacement of wear parts.
• Patented Smart Trim system enables quick and easy impeller clearance adjustment, without dismantling the pump, in order to maintain peak performance.
