Grundfos 97734006 - Model CRN 15-2 H, Horizontal End-Suction Multistage Centrifugal Pump

SKU: 97734006
Regular price $5,378.24

Got questions?

Feel free to get in touch

Grundfos CRN 15 H Complete Unit Horizontal End Suction Multistage Centrifugal Pump

The Grundfos CRN 15 H offers optimized duty points to maximize pump efficiency and minimize internal wear. The benefit of the CRN 15 H pump is significant reduction in energy costs, maintenance effort and downtime along with increased pump life.

Features:

  • Reliability
  • High efficiency
  • Service-friendly
  • Space-saving
  • Suitable for slightly aggressive liquids
  • High corrosion resistance
  • Single-pump solution making high pressures possible

Applications:

  • Industrial / Chemical Processing systems
  • Washing and cleaning systems
  • Pumping of acids and alkalis
  • Filtration systems
  • Water Pressure Boosting
  • Water Treatment
  • HVAC
  • Irrigation
Brand Grundfos
Mfg. Number 97734006
Model CRN 15-2 H
Series CRN 15 H
Connection GA
Horsepower 5 HP
NEMA Size 182TC
Voltage 208-230/460 Volts
Phase 3
Frequency 60 Hz
RPM 3540 RPM
Shaft Seal Type HQQE
Stages 2
Construction Material 316 Stainless Steel
Impeller Material 316 Stainless Steel
Motor Cooling Type TEFC
Motor Type 112CA
Max. Water Temperature 250°F
Suction 1-1/2" NPT
Discharge 1" NPT
Maximum Total Head 121.52 ft
Maximum Flow 127.63 GPM
