Specifications: \n \nStainless Steel - bodied shallow well jet pump prevents corrosion in harsh environments. High volume output for high-demand usage in homes and for small sprinkler systems. \n
\n - Superior Performance At depths of water to 25’ or less
\n - Rugged Stainless Steel Construction For highest corrosion resistance
\n - Heavy-Duty Dual-Voltage Motor Pre-set at 230V (see manual for 115V conversion)
\n - Pre-Wired Pressure Switch Pre-set for 30/50 PSI operation
\n - Self-Priming after Pump Housing is Initially Filled Check valve or foot valve required, sold separately
\n
\n
\n \n \n| Body Construction | \nStainless Steel | \n
\n \n| Horsepower | \n1 HP | \n
\n \n| Maximum Capacity | \n16.2 GPM | \n
\n \n| Flow at 10' Lift and 40 PSI | \n14.6 GPM | \n
\n \n| Max Lift | \n25' | \n
\n \n| Max Shut-Off Pressure | \n80 PSI | \n
\n \n| Maximum Inlet Pressure | \n50 PSI | \n
\n \n| Pressure Switch Setting | \n30/50 | \n
\n \n| Suction Size | \n1-1/4" NPT | \n
\n \n| Discharge Size | \n1" NPT | \n
\n \n| Amp Draw (full load) | \n9.6 amps on 230v / 19.2 amps on 115v | \n
\n \n| Voltage | \n230v / 115v AC, 60 Hz (factory pre-set to 230v) | \n
\n \n| Recommended Breaker | \n15 Amp on 230v / 20 Amp on 115v | \n
\n \n| Maximum Water Temperature | \n122 F (50 C) | \n
