Specifications: \n \nThe Sink Pump System is an economical, above-floor, corrosion-resistant pump system for home gray water handling applications such as laundry or wet bars. \n
\n - Compact box for easy under-sink installation
\n - Includes energy-efficient 1/4 HP pump
\n
\n
\n \n \n| Body Construction | \nThermoplastic Pump / Structural foam Basin & Lid | \n
\n \n| Horsepower | \n1/4 HP | \n
\n \n| Maximum Head | \n18' | \n
\n \n| Maximum Capacity | \n2880 GPH | \n
\n \n| Flow at 10' Lift | \n1620 GPH | \n
\n \n| Switch Type | \nVertical | \n
\n \n| Discharge Pipe Size | \n1-1/2" | \n
\n \n| Minimum Pipe Size | \n1-1/4" | \n
\n \n| Maximum Solids Handling | \n1/8" | \n
\n \n| Amp Draw | \n8.5 amps at max load | \n
\n \n| Voltage | \n115v AC, 60 Hz | \n
\n \n| Recommended Breaker | \n15 amps | \n
\n \n| Maximum Fluid Temperature | \n130°F (54°C) | \n
\n \n
