Mosherflo MFPSTX433040001-CI - Trash Pump ST-X4 CI - Self Priming Pump
Overview
Mosherflo Trash Pump / Self Priming Pump with (TC/TC) seal assy and standard cast iron impeller.
OEM Part number: T4A3S-B/F
OEM Part number: T4A60S-B/F
OEM Part number: SN04SA-PUMP-STD
OEM numbers are used for reference purposes only.
Features
- Adjustable back cover plate to set the impeller clearance
- Two sight glasses
- Slightly larger shaft at the bearing fit compare to standard model
- 3 oil seals
- Ability to adjust the impeller clearance from the outside of the pump
- Material: Cast Iron
- Quick and simple maintenance
- Cleaning and inspection without disconnecting the pipework (Back - Pull - Out)
- Shimless external impeller adjustment
- 12 months warranty
Specifications
- Up to 119 ft. of head and 730 GPM flow
- Length 32"
- Width 19.75"
- Height 29.19"
- Weight 600Lbs.
- Impeller diameter 9 - 3/4"
- RPM From 650 rpm to 1950 rpm
- Max. Solids 3"
- Self-priming 25 ft
- Max flow. 730 gpm
