Goulds S34063, 3 Phase, 4.0-6.3 Amps, Weatherproof Simplex Control Panel
Regular price
$2,132.39
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary:
- Oversize enclosure to accommodate all options.
- One main disconnect through-the-door with door interlock, prevents the door from accidentally being opened when the disconnect is in the ON position. Pad-lockable in the OFF position only.
- A manual lockable disconnect feature on the motor overload protector. Lock not provided.
- Oversize magnetic contactor.
- Overload. Ambient compensated bi-metallic (Class 10) motor overload circuit protector. Instantaneous magnetic trip for short circuit protection. Single-phase protection for three-phase motor. Field adjustable within the amp. range.
- Control transformer with fused primary and fused secondary on all three-phase. Single- phase 115 volt has a fused control circuit.
- Pump test switch. Three-position HOA (hand-off-automatic).
- Green light indicates power to pump motor, mounted on the door
- Control terminal board, numbered and wired.
- Layout and schematic CAD diagrams can be provided upon request.
- Optional alarm circuit may be field modified to use a 115 volt AC external power source.
| Brand | Goulds |
| Mfg. Number | S34063 |
| Series | SES |
| Product Type | Weatherproof simplex control panel |
| Application | Indoor/Outdoor |
| Phase | 3 |
| Amp Range | 4.0 - 6.3 Amps |
| Enclosure Type | NEMA 4X |
| Enclosure Material | Fiberglass |
| Hardware Material | Stainless steel |
| Indicator Lights | Alarm/Run |
| Width | 11.3" |
| Height | 16.3" |
| Depth | 11.3" |
| Modifiable | Yes |
