Flotec

Flotec FP4322-08, 3/4HP, 115/230V, Thermoplastic Convertible Jet Pump

SKU: FP4322-08
$515.21

Got questions?

Feel free to get in touch

Summary: Corrosion resistant convertible jet pumps are constructed of rugged fiberglass-reinforced thermoplastic, and assure years of dependable service.

Key Features:

  • Superior performance at depths to water of 100' or less
  • Fiberglass-reinforced thermoplastic pump housing for the highest corrosion resistance
  • Ready-to-install 230 volt motor - see manual for 115 volt conversion

Details:

Body Construction Thermoplastic
Horsepower 3/4 HP
Maximum Capacity 15.3 GPM (shallow well)
Flow at 10' Lift and 40 PSI 13.8 GPM (shallow well)
Max Lift 25' (shallow well) / 100' for 4" deep setup
Max Pressure 52 PSI (deep well) / 66 PSI for 4" deep setup
Pressure Switch Setting 30/50
Suction Pipe Size 1-1/4" NPT
Discharge Pipe Size 1" NPT
AMP Draw (full load) 6.1 amps on 230V / 12.2 amps on 115v
Voltage 230v/115v, 60 Hz
Recommended Breaker 15 amps on 230v / 20 amps on 115v
Maximum Temperature 140 °F (60 °C)
