BJM LWAE22, 204229, 3HP, 230V, Lightweight Agitator Pump
Regular price
$3,876.00
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: Submersible Light-Weight Agitator Dewatering Pumps
- Hard Metal Submersible dewatering pumps
- Designed and constructed for dewatering sand, silt, coal fines and abrasive light slurries.
- Chrome Iron impeller and wear plate
- Hardened ductile iron agitator and volute
- Built-in agitator mixes settled solids with pump water to restore sump or basin volume
- Light Weight
| MAX. FLOW: GPM | 255 |
|---|---|
| MAX. HEAD: ft | 61' |
| PUMP TYPE | Top Discharge, Dewatering, Agitator |
| DISCHARGE SIZE | 3" NPT |
| MAX. SUBMERGED DEPTH | 65' |
| MIN. SUBMERGED DEPTH | 7.6" |
| SHIPPING WEIGHT:lbs | 135 |
| MOTOR CASING | 304SS |
|---|---|
| PUMP VOLUTE | ASTM A48 CLASS 30 CAST IRON |
| LIP SEALS & O-RINGS | BUNA-N |
| ROTOR SHAFT | 304SS |
| EXTERNAL HARDWARE | 304SS |
| MOTOR RATING: HP | 3 |
|---|---|
| MOTOR RPM | 3450 |
| MOTOR INSULATION CLASS | F |
| MOTOR SERVICE FACTOR | 1.15 |
| VOLTAGE | 230 |
| CURRENT F.L.A. | 8.6 |
| MOTOR PROTECTION | AUTO RE-SET AMP OVERLOAD SWITCH |
| POWER CORD: GAGE; LENGTH | A.W.G 14/5; 50'; SOOW |
| MAXIMUM LIQUID TEMPERATURE | 104°F |
