BJM S55C, 201420, 7.5HP, 460V, 3 Phase, Cast Iron, Non-Clog Pump
Regular price
$7,315.00
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: The S-pumps have non-clog, single vane impellers designed for high volume and lift performance. ALSO AVAILABLE IN 316 CAST STAINLESS STEEL (SX-Series)
- Longer Power Cord - Standard 33ft. power cord.
- 304SS Motor Housing - Superior abrasion resistance will not wear out like aluminum motor housings when pumping sandy water.
- Three Seal Motor Protection - Motor is protected by double mechanical seals. Lower seal made of silicon carbide/silicon carbide and upper seal is made of carbon/ceramic. An additional lip seal has been installed above the impeller, to help prevent abrasives such as dirt, silt or sand, from entering into the seal chamber.
- More Motor Protection - Winding protection and (NEMA) Class F motor insulation allows motor temperature to raise to 230°F, superior to pumps with Class A and B insulation. Automatic switch turns pump motor off if temperature and/or amp draw raises too high. When the motor cools the switch will automatically reset and the pump will turn back on.
- Tough Pump Construction - Hardened cast iron stands up to rough handling and pumping sandy water unlike pumps with soft resin impellers or plastic exterior components.
| MAX. FLOW: GPM | 450 |
|---|---|
| MAX. HEAD: ft | 78' |
| PUMP TYPE | Open Vane Non Clog |
| DISCHARGE SIZE | 4" NPT-F |
| MAX. SUBMERGED DEPTH | 65' |
| MIN. SUBMERGED DEPTH | 19" |
| SHIPPING WEIGHT:lbs | 247 |
| MOTOR CASING | 304 SS |
|---|---|
| PUMP VOLUTE | Cast Iron |
| STRAINER / STAND | Cast Iron |
| LIP SEALS & O-RINGS | Buna-N |
| ROTOR SHAFT | 304 SS |
| EXTERNAL HARDWARE | 304 SS |
| QTY. OIL IN SEAL CHAMBER | 35.5 U.S. FL. OZ. |
| MOTOR RATING: HP | 7.5 |
|---|---|
| MOTOR RPM | 3450 |
| MOTOR INSULATION CLASS | H |
| MOTOR SERVICE FACTOR | 1.1 |
| VOLTAGE | 460, 3PH-60 Hz |
| CURRENT F.L.A. | 10.5 |
| MOTOR PROTECTION | Thermal & Amp Overload |
| POWER CORD: GAGE; LENGTH | A.W.G. 10/4; 33', SOOW |
| MAXIMUM LIQUID TEMPERATURE | 104° F |
| Seal Minder® | Standard/Included |
