Summary: "The Bullet" pumps are ideal for dewatering constructions sites, mines, or for all around use in industrial plants and utilities.
-
Top Discharge - allows for superior cooling of motor and provides a slim line design.
-
Longer Power Cord - Standard 33ft. power cord on pumps ½ HP and below and 50ft. on pumps 1HP and above.
-
304SS Motor Housing - Superior abrasion resistance will not wear out like aluminum motor housings when pumping sandy water.
-
Three Seal Motor Protection - Motor is protected by double mechanical seals. Lower seal made of silicon carbide/silicon carbide and upper seal is made of carbon/ceramic*. An additional lip seal has been installed above the impeller, to help prevent abrasives such as dirt, silt or sand, from entering into the seal chamber.
-
More Motor Protection - Winding protection and (NEMA) Class F motor insulation allows motor temperature to raise to 230°F, superior to pumps with Class A and B insulation. Automatic switch turns pump motor off if temperature and/or amp draw raises too high. When the motor cools the switch will automatically reset and the pump will turn back on.
-
Tough Pump Construction - Hardened cast iron stands up to rough handling and pumping sandy water unlike pumps with soft resin impellers or plastic exterior components*.
-
R400D Special Feature - "The Mop Up Pump", will pump down to 1/12th of an inch. It features a special diaphragm value that prevents water backflow.
The Silver Bullet®and Mop-Up® are both registered trademarks of BJM Pumps, LLC. The Bullet
™ is a trademark of BJM Pumps, LLC. * Exception: R400D impeller made of fiberglass reinforced Noryl. Lower seal carbon/ceramic.
Details:
GENERAL DATA | MAX. FLOW: GPM | 47.5 |
| MAX. HEAD: ft | 26.2' |
| PUMP TYPE | Top Discharge, Dewatering |
| STRAINER OPENING | 0.1875" |
| DISCHARGE SIZE | 1.5" NPT-M |
| MAX. SUBMERGED DEPTH | 65' |
| SHIPPING WEIGHT:lbs | 32 |
CONSTRUCTION/MATERIAL DATA | MOTOR CASING | 304SS |
| PUMP VOLUTE | Cast Iron |
| IMPELLER - MULTI VANE | Cast Iron |
| LIP SEALS & O-RINGS | Buna-N |
| ROTOR SHAFT | 304 SS |
| EXTERNAL HARDWARE | 304 SS |
| QTY. OIL IN SEAL CHAMBER | 1.35 U.S. FL. OZ. |
ELECTRICAL/MOTOR DATA | MOTOR RATING: HP | 0.33 |
| MOTOR RPM | 3450 |
| MOTOR INSULATION CLASS | B |
| MOTOR SERVICE FACTOR | 1.0 |
| VOLTAGE | 115, 1PH-60Hz |
| CURRENT F.L.A. | 4 |
| MOTOR PROTECTION | Thermal Breaker |
| POWER CORD: GAGE; LENGTH | A.W.G. 16/3; 33', STOW |
| MAXIMUM LIQUID TEMPERATURE | 104° F |
| Seal Minder® | Not Available |
