BJM KB55H, 201276, 7.5HP, 230V, Heavy Duty Dewatering/High Head Agitator Pump

SKU: 201276
$8,882.50

Got questions?

Feel free to get in touch

Summary: KB Series Submersible pumps feature…
  1. Abrasive resistant chrome iron components;
    • Agitator - to fluidize settled solids into suspension.
    • Wear plate - replaceable hardened surface on the suction side where erosion would cause a loss of pump performance.
    • Semi- open Impeller - to handle some solids.
  2. EVERY KB pump model is protected by;
    • Class H motor insulation - and built in amperage ( FLA ) and temperature overload protection.
    • Double mechanical seals - SiC/SiC lower & Carbon Ceramic upper in a separate oil filled seal chamber.
    • Heavy Duty Lip Seal - additional protection for the mechanical seals.
    • Stainless steel shaft and shaft sleeve - saves on shaft wear due to abrasives and corrosion.
  3. The KB Series are top discharge pumps;
    • KB pumps are utility pumps - frequently dragged from one site to another. The KB doesn’t have a side discharge connection that can break off or be damaged as it is pulled and pushed into place.
    • Top discharge pumps are cooled by pumped liquid - The KB pumps can pump a sump or pit down to within "inches" of the bottom. A side discharge pump without a cooling jacket must stay submerged to avoid overheating, leaving as much as 3 feet of un-pumped slurry.
    • Top discharge means "SLIM" - even the largest model with a 13.5 inch "waistline" will fit down a manhole with a hose attached.   High-Chrome Agitator helps keep solids suspended in liquid and helps prevent pump from clogging.
High-Chrome Agitator helps keep solids suspended in liquid and helps prevent pump from clogging. Details:
GENERAL DATA
MAX. FLOW: GPM 277
MAX. HEAD: ft 117'
PUMP TYPE Top Discharge, Dewatering
DISCHARGE SIZE 3" NPT-M
MAX. SUBMERGED DEPTH 65'
SHIPPING WEIGHT:lbs 335

CONSTRUCTION/MATERIAL DATA
MOTOR CASING Cast Iron
PUMP VOLUTE Ductile Iron
IMPELLER - MULTI VANE Hi-Chrome
LIP SEALS & O-RINGS Buna - N
ROTOR SHAFT 304 SS
EXTERNAL HARDWARE 304 SS
QTY. OIL IN SEAL CHAMBER 49 U.S. FL. OZ.

ELECTRICAL/MOTOR DATA
MOTOR RATING: HP 7.5
MOTOR RPM 3450
MOTOR INSULATION CLASS H
MOTOR SERVICE FACTOR 1.1
VOLTAGE 230, 3ph-60Hz
CURRENT F.L.A. 20.4
MOTOR PROTECTION Thermal & Amp Overload
POWER CORD: GAGE; LENGTH A.W.G. 10/5; 50', SOOW
MAXIMUM LIQUID TEMPERATURE 104° F
Seal Minder® Optional
