BJM J15H, 201191, 2HP, 460V, 3 Phase, Cast Iron, High Head Sump Pump
Regular price
$3,030.50
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: The JH-Series electric submersible pumps offer top performance and high quality for a very modest investment. The pumps are designed for long life and trouble free performance.
- TWO PUMPS IN ONE Most J-Series pumps can quickly be converted from High Volume to High Head (or vice-versa) by merely changing the impeller and the suction plate. Other brands often require major changes to achieve different heads or volumes.
- Motor casings, hardware and impeller shafts are made from 304 stainless steel, with all other exposed parts made of cast iron.
- Pumps 1/2HP and above, feature double mechanical seals which work in a separate oil chamber
- Oil seal ring(s) are installed above the impeller to help keep impurities and abrasives away from the mechanical seals.
- All pumps are equipped with an overload protection which guards against low and high amperage as well as excessive temperature.
- SLIDE RAIL SYSTEMS The J55H and J75H can also be mounted on the BJM slide rail system.
| MAX. FLOW: GPM | 105 |
|---|---|
| MAX. HEAD: ft | 75' |
| PUMP TYPE | Sump, Side Discharge |
| STRAINER OPENING | 0.5625" x 0.25" Slot |
| DISCHARGE SIZE | 2" NPT-M |
| MAX. SUBMERGED DEPTH | 65' |
| MIN. SUBMERGED DEPTH | 9.5" |
| SHIPPING WEIGHT:lbs | 69 |
| MOTOR CASING | 304SS |
|---|---|
| PUMP VOLUTE | Cast Iron |
| IMPELLER - MULTI VANE | Cast Iron |
| LIP SEALS & O-RINGS | Buna - N |
| ROTOR SHAFT | 304 SS |
| EXTERNAL HARDWARE | 304 SS |
| QTY. OIL IN SEAL CHAMBER | 9 U.S. FL. OZ. |
| QTY. OIL IN MOTOR STATOR | No oil in motor stator (After ser#42043) 13.5 U.S. FL. OZ. (Before ser# 42043) |
| MOTOR RATING: HP | 2 |
|---|---|
| MOTOR RPM | 3450 |
| MOTOR INSULATION CLASS | F |
| MOTOR SERVICE FACTOR | 1.1 |
| VOLTAGE | 460, 3ph-60 Hz |
| CURRENT F.L.A. | 3 |
| MOTOR PROTECTION | Thermal & Amp Overload |
| POWER CORD: GAGE; LENGTH | A.W.G 16/4, 33', STOW |
| MAXIMUM LIQUID TEMPERATURE | 104° F |
| Seal Minder® | Optional |
