BJM J15, 201185, 2HP, 208V, 3 Phase, Cast Iron Sump Pump

SKU: 201185
$3,486.50

Got questions?

Feel free to get in touch

Summary: The J-Series electric submersible pumps offer top performance and high quality for a very modest investment. The pumps are designed for long life and trouble free performance.
  • TWO PUMPS IN ONE Most J-Series pumps can quickly be converted from High Volume to High Head (or vice-versa) by merely changing the impeller and the suction plate. Other brands often require major changes to achieve different heads or volumes.
  • Motor casings, hardware and impeller shafts are made from 304 stainless steel, with all other exposed parts made of cast iron
  • Pumps 1/2HP and above, feature double mechanical seals which work in a separate oil chamber.
  • Oil seal ring(s) are installed above the impeller to help keep impurities and abrasives away from the mechanical seals.
  • All pumps are equipped with an overload protection which guards against low and high amperage as well as excessive temperature
  • SLIDE RAIL SYSTEMS The J55 and J75 can also be mounted on the BJM slide rail system.
Details:
GENERAL DATA
MAX. FLOW: GPM 158
MAX. HEAD: ft 60'
PUMP TYPE Sump, Side Discharge
STRAINER OPENING 0.5625" x 0.25" Slot
DISCHARGE SIZE 3" NPT-M
MAX. SUBMERGED DEPTH 65'
MIN. SUBMERGED DEPTH 9.5"
SHIPPING WEIGHT:lbs 69

CONSTRUCTION/MATERIAL DATA
MOTOR CASING 304SS
PUMP VOLUTE Cast Iron
IMPELLER - MULTI VANE Cast Iron
LIP SEALS & O-RINGS Buna - N
ROTOR SHAFT 304 SS
EXTERNAL HARDWARE 304 SS
QTY. OIL IN SEAL CHAMBER 9 U.S. FL. OZ.
QTY. OIL IN MOTOR STATOR No oil in motor stator (After ser# 42043) 13.5 U.S. FL. OZ. (Before ser# 42043)

ELECTRICAL/MOTOR DATA
MOTOR RATING: HP 2
MOTOR RPM 3450
MOTOR INSULATION CLASS F
MOTOR SERVICE FACTOR 1.1
VOLTAGE 208, 3ph- 60 Hz
CURRENT F.L.A. 6.3
MOTOR PROTECTION Thermal & Amp Overload
POWER CORD: GAGE; LENGTH A.W.G. 16/4, 33', STOW
MAXIMUM LIQUID TEMPERATURE 104° F
Seal Minder® Optional
