Berkeley B85758, B10JPBH Model, 200HP, 230-460V, 3 Phase, B Series, Close Coupled Centrifugal Pump
Regular price
$49,582.60
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: BERKELEY Close-Coupled End-Suction Pumps are ideal for most applications requiring high performance, easy maintenance and moderate initial cost. Cast Iron construction with unique back pull-out design permits access to the impeller without disturbing the piping.Four-Position Discharge
- Premium-Grade Motors
- Motor Bracket
- Maintenance-Free Shaft Seal
- Replaceable Slip-On Shaft Sleeve
- Replaceable Bronze Wear Ring
- Superior Impeller
- Heavy-Duty Volute Case
- Multiple Taps
- Durable Finish
| Brand | Berkeley |
| Mfg. Number | B85758 |
| Model | B10JPBH |
| Product Type | Centrifugal pump |
| Series | B Series |
| Application | Residential/industrial/agricultural |
| Horsepower | 200 HP |
| Voltage | 208-230/460 volts |
| Phase | 3 |
| Speed | 1800 RPM |
| Design | Close-coupled |
| Suction Connection | 12" Flanged |
| Discharge Connection | 10" Flanged |
| Pump Size | (10x12x13 PBH) |
| Impeller Diameter | 13" |
| Impeller Material | Cast Iron |
| Pump Casing Material | Cast iron |
| Shaft Seal | Packing |
| Enclosure | ODP |
