Berkeley B5ZPBHS, B85696, 25HP, 230-460V, 3 Phase, Close Coupled Centrifugal Pump
Regular price
$10,421.06
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: BERKELEY Close-Coupled End-Suction Pumps are ideal for most applications requiring high performance, easy maintenance and moderate initial cost. Cast Iron construction with unique back pull-out design permits access to the impeller without disturbing the piping. KEY FEATURES
- Four-Position Discharge
- Premium-Grade Motors
- Motor Bracket
- Maintenance-Free Shaft Seal
- Replaceable Slip-On Shaft Sleeve
- Replaceable Bronze Wear Ring
- Superior Impeller
- Heavy-Duty Volute Case
- Multiple Taps
- Durable Finish
| Brand | Berkeley |
| Mfg. Number | B85696 |
| Model | B5ZPBHS |
| Product Type | Centrifugal pump |
| Series | B Series |
| Application | Residential/industrial/agricultural |
| Horsepower | 25 HP |
| Voltage | 208-230/460 volts |
| Phase | 3 |
| Speed | 1800 RPM |
| Design | Close-coupled |
| Suction Connection | 6" Flanged |
| Discharge Connection | 5" Flanged |
| Pump Size | (5X6X9 BH) |
| Impeller Diameter | 9" |
| Impeller Material | Cast Iron |
| Pump Casing Material | Cast iron |
| Shaft Seal | Mechanical |
| Enclosure | ODP |
