Berkeley B80375, B6JQBM Model, Centrifugal SAE Mount Pump End
Regular price
$12,132.22
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: The new standard in full-performance reliability... Berkeley S.A.E. End Suction Pumps are suitable for any application requiring the convenience of an internal combustion engine as a power source. State-of-the-art design delivers 20,000 hours of bearing life, one of the industry's longest life cycles.
- Twenty-eight pump models, with flows to 6500 GPM, Pressures to 500 feet (215 psig).
- Cast Iron or Silicon Bronze Impellers are available in either packed or mechanical seal configurations. Replaceable stainless steel shaft sleeve is standard, providing maximum corrosion resistance while minimizing shaft wear.
- Volute case - Back pull-out design allows easy removal and repair without disturbing piping connections, and completely exposes the impeller for flushing or service.
- Heavy-Duty Power Frame is designed for durability delivering in excess of 20,000 hours of bearing life. Includes large shaft and grease-for-life sealed bearings to handle the toughest conditions with less maintenance and more reliability.
| Brand | Berkeley |
| Mfg. Number | B80375 |
| Series | B Series |
| Model | B6JQBM |
| Product Type | Centrifugal SAE mount |
| Application | Residential/commercial/agricultural |
| Design | End-suction |
| Suction Connection | 8" Flanged |
| Discharge Connection | 6" Flanged |
| Pump Size | (6 x 8 x 13 BM) |
| Impeller Size | 13" |
| Impeller Material | Cast iron |
| Shaft Seal | Packing |
| Shaft Spline Size | 1-1/2"-10T |
| Shaft Extension | 3" |
| SAE HSG Size | 4 |
