Berkeley B80357, B3ZRM Model Hydraulic Motor Drive Centrifugal Pump
Regular price
$4,780.99
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: Berkeley Type B frame-mount centrifugal pumps are designed for the user who has a separate power source suitable for driving through couplings or with belts. Ideal for all general purpose applications requiring high performance, moderate initial cost and easy maintenance.
- Volute Case Incorporates Precise Geometric Design for Increased Hydraulic Efficiency
- Thick-Walled Close-Grained Cast Iron to Handle the Stresses of Everyday Use
- Back Pull-Out Design Allows Easy Removal And Service Without Disturbing Piping Connections
- Enclosed Impeller Designed and Machined to Optimize Performance and Operating Efficiencies
- Discharge May Be Rotated To Any of Four Positions for Piping Convenience
| Brand | Berkeley |
| Mfg. Number | B80357 |
| Model | B3ZRM |
| Product Type | Hydraulic motor drive centrifugal pump |
| Series | B Series |
| Application | Residential/Industria/ Agricultural |
| Suction Connection | 4" NPT |
| Discharge Connection | 3" NPT |
| Pump Size | (3 x 4 x 9 M) |
| Impeller Diameter | 9" |
| Impeller Material | Cast iron |
| Pump Casing Material | Cast iron |
| Shaft Seal | Packing |
| Rotation | Clockwise |
