Berkeley Model B3TPM, B69868, 3HP, 115-230V, 1 Phase, Close-Coupled Centrifugal Pump
Regular price
$4,685.89
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: BERKELEY Close-Coupled End-Suction Pumps are ideal for most applications requiring high performance, easy maintenance and moderate initial cost. Cast Iron construction with unique back pull-out design permits access to the impeller without disturbing the piping. Key Features:
- Four-Position Discharge
- Premium-Grade Motors
- Motor Bracket
- Maintenance-Free Shaft Seal
- Replaceable Slip-On Shaft Sleeve
- Replaceable Bronze Wear Ring
- Superior Impeller
- Heavy-Duty Volute Case
- Multiple Taps
- Durable Finish
| Brand | Berkeley |
| Mfg. Number | B69868 |
| Series | B Series |
| Model | B3TPM |
| Product Type | Centrifugal Pump |
| Application | Residential/industrial/agricultural |
| Horsepower | 3 HP |
| Voltage | 115/230 volts |
| Phase | 1 |
| Speed | 1750 RPM |
| Design | Close-coupled |
| Suction Connection | 8" NPT |
| Discharge Connection | 6" NPT |
| Pump Size | (6 x 8 x 9 L) |
| Impeller Material | Cast iron |
| Pump Casing Material | Cast iron |
| Shaft Seal | Packing |
| Enclosure | TEFC |
