Summary: Berkeley Type B Frame-Mount centrifugal pumps are designed for the user who has a separate power source suitable for driving through couplings or with belts. Ideal for all general purpose applications requiring high performance, moderate initial cost and easy maintenance.
KEY FEATURES - Volute case incorporates precise geometric design for increased hydraulic efficiency
- Thick-walled close-grained cast iron to handle the stresses of everyday use
- Back pull-out design allows easy removal and service without disturbing piping connections
- Enclosed impeller designed and machined to optimize performance and operating efficiencies
- Discharge may be rotated to any of four positions for piping convenience
Details: | Brand | Berkeley |
| Mfg. Number | B68416 |
| Model | B3ZRMS |
| Product Type | Centrifugal frame mount |
| Series | B Series |
| Application | Residential/industrial/agricultural |
| |
| |
| |
| |
| Design | End-suction |
| Suction Connection | 4" Victaulic |
| Discharge Connection | 3" Victaulic |
| Pump Size | (3 x 4 x 9 M) Standard Frame |
| Impeller Diameter | 9" |
| Impeller Material | Cast Iron |
| |
| Shaft Seal | Mechanical |
| Rotation | |
