Summary: Berkeley Type B frame-mount centrifugal pumps are designed for the user who has a separate power source suitable for driving through couplings or with belts. Ideal for all general purpose applications requiring high performance, moderate initial cost and easy maintenance.
- Volute Case Incorporates Precise Geometric Design for Increased Hydraulic Efficiency
- Thick-Walled Close-Grained Cast Iron to Handle the Stresses of Everyday Use
- Back Pull-Out Design Allows Easy Removal And Service Without Disturbing Piping Connections
- Enclosed Impeller Designed and Machined to Optimize Performance and Operating Efficiencies
- Discharge May Be Rotated To Any of Four Positions for Piping Convenience
Detail: | Brand | Berkeley |
| Mfg. Number | B66488S |
| Series | B Series |
| Model | B1-1/2ZPL |
| Product Type | Centrifugal Pump |
| Application | Residential/industrial/agricultural |
| Horsepower | 7.5 HP |
| Voltage | 208-230/460 volts |
| Phase | 3 |
| Speed | 3600 RPM |
| Design | Close-coupled |
| Suction Connection | 2" NPT |
| Discharge Connection | 1-1/2" NPT |
| Pump Size | (1-1/2 x 2 x 9 L) |
| Impeller Material | Silicon Bronze |
| Pump Casing Material | Cast iron |
| Shaft Seal | Packing |
| Enclosure | ODP |
