Berkeley Model B3TPM, B53816EF1, 10HP, 208-230/460V, 3 Phase, Close-Coupled Centrifugal Pump
Regular price
$6,301.96
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Summary: BERKELEY Close-Coupled End-Suction Pumps are ideal for most applications requiring high performance, easy maintenance and moderate initial cost. Cast Iron construction with unique back pull-out design permits access to the impeller without disturbing the piping. Key Features:
- Four-Position Discharge
- Premium-Grade Motors
- Motor Bracket
- Maintenance-Free Shaft Seal
- Replaceable Slip-On Shaft Sleeve
- Replaceable Bronze Wear Ring
- Superior Impeller
- Heavy-Duty Volute Case
- Multiple Taps
- Durable Finish
| Brand | Berkeley |
| Mfg. Number | B53816EF1 |
| Series | B Series |
| Model | B3TPM |
| Product Type | Centrifugal Pump |
| Application | Residential/industrial/agricultural |
| Horsepower | 10 HP |
| Voltage | 208-230/460 volts |
| Phase | 3 |
| Speed | 3600 RPM |
| Design | Close-coupled |
| Suction Connection | 4" NPT |
| Discharge Connection | 3" NPT |
| Pump Size | (3 x 4 x 6 M) |
| Impeller Material | Cast Iron |
| Pump Casing Material | Cast iron |
| Shaft Seal | Packing |
| Enclosure | TEFC |
