Barnes 141375N - Blade Model NGVHH150N2 NGVHH – Submersible Grinder Pump

SKU: 141375N_208/230V
$8,308.92
Voltage

Got questions?

Feel free to get in touch

Barnes NGVHH150N2 Blade Grinder Pump Non-Explosion Proof, Horizontal, Flanged Discharge, 21 frame, Part Number: 141375N. 15 HP, 208-230 or 460 Volt, 60 Hz, 3 Phase, 3450 RPM. Cord Sold Separately

Please add to order for the power cord:

  • 125498XC / 30ft. (208-230 V)
  • 125498XF / 50ft. (208-230 V)
  • 125497XC / 30ft. (460 V)
  • 125497XF / 50ft. (460 V)

Blade grinder pumps are the ideal pump for solids handling applications requiring high head and low flow when a 2 HP residential grinder can’t meet performance requirements.

  • Specialized for applications requiring flow between 30 and 130 gpm
  • Engineered for use in areas with high water tables and potential for I&I
  • Vortex impellers provide non-overloading capabilities to handle fluctuating head conditions from force mains
  • Built for light commercial applications including strip malls, restaurants, warehouses, gas stations or apartment buildings

DISCHARGE:

Horizontal 2.50"/3"

LIQUID TEMPERATURE:

104°F (40°C) Continuous

VOLUTE:

Cast iron ASTM A-48, class 30

MOTOR HOUSING:

Cast iron ASTM A-48, class 30

SEAL PLATE:

Cast iron ASTM A-48, class 30

IMPELLER:

Design: 12 Vane vortex, with pump out vanes on back side. Dynamically balanced, ISO G6.3

Material: Cast iron ASTM A-48, class 30

SHREDDING RING:

Hardened 440C stainless steel, Rockwell® C-55

CUTTER:

Hardened 440C Stainless Steel, Rockwell® C-55

SHAFT:

416 Stainless steel

SQUARE RINGS:

Buna-N

HARDWARE:

300 Series stainless steel

PAINT:

Axalta™ Corlar® Epoxy, two coats

SEAL:

Design:Tandem mechanical, oil filled reservoir

Material:

  • Rotating faces: Carbon

  • Stationary faces: Ceramic

  • Elastomer: Buna-N

  • Hardware: 300 Series stainless

Hardware: 300 Series Stainless

CORD ENTRY:

Custom molded, quick connected for sealing and strain relief

POWER CORD:

CSA certified submersible power cable 2000V - ordered separately

UPPER BEARING:

Design:Single row, ball

Lubrication: Oil

Load:Radial

LOWER BEARING:

Design:Double row, ball

Lubrication:Oil

Load:Radial & thrust

MOTOR:

Design:

  • NEMA B

  • Three phase torque curve

  • Oil-filled squirrel cage induction

  • Inverter duty rated per NEMA MG1

Insulation:Class H varnish & magnet wire

SINGLE PHASE:

Requires overload protection to be included in control panel. Requires start components to be included in panel. Provided with pump

THREE PHASE:

Requires overload protection to be included in control panel

MOISTURE SENSORS:

Normally open (N/O), Requires relay in control panel

TEMPERATURE SENSOR:

Normally closed (N/C) To be wired in series with control circuit
